Projects My First Custom - Shoebox Project

Discussion in 'The Hokey Ass Message Board' started by the-rodster, Aug 26, 2010.

  1. bigbren
    Joined: Apr 1, 2009
    Posts: 31

    bigbren
    Member

    I am now subscribed! Keep it up. I'm halfway through the rebuild on my 53 flatty. Then I will look for a car!

  2. Lono
    Joined: May 10, 2007
    Posts: 1,656

    Lono
    Member


    Yep, I agree, they're sweet. Aren't they off a 49-51 Merc?

  3. Buddy Palumbo
    Joined: Mar 30, 2008
    Posts: 3,871

    Buddy Palumbo
    Member

    Back in the day that style skirt was a Merc skirt , that guys had to cut down to fit a Shoebox . Later on a company named Foxcraft made them out of steel that bolted right on , with the correct height to fit below a Shoebox's sidetrim . I owned a few in the past year (kept one pair for my car) .

  4. the-rodster
    Joined: Jul 2, 2003
    Posts: 6,960

    the-rodster
    Member

    Here ya go, everything you wanted to know about shoebox skirts....

    http://www.jalopyjournal.com/forum/showthread.php?t=652658

    Rich

  5. grf-x
    Joined: Jul 15, 2010
    Posts: 299

    grf-x
    Member

    Thanks rich I appreciate it!

  6. rodknocker
    Joined: Jan 31, 2006
    Posts: 2,265

    rodknocker

    The car is looking great, just a question, what are your plans with exhaust on the drivers side, looks like its going to be tight. I know with mine w/o the p/s and a sbc cuts it real close with the block huggers.

  7. the-rodster
    Joined: Jul 2, 2003
    Posts: 6,960

    the-rodster
    Member

    I'm dressing the engine up like a stock 56 chevy, so I wanted to run some type of OEM cast manifold.

    Rams horn center dump won't work, rams horn angled dump (truck) didn't work either.

    I went with this...

    [​IMG]

    82 - 92 Camaro ??

    I think they look the part, and clear everything (very close to the upper A arm)

    I'll post new pics soon.

    Rich

  8. 48flthdf1
    Joined: Apr 26, 2011
    Posts: 160

    48flthdf1
    Member

    Rich...You Are the man..Very nice work...Subsribed

  9. Beachcomber
    Joined: Aug 4, 2010
    Posts: 283

    Beachcomber
    Member
    from Phoenix,AZ

    Shit! The ram horns dont clear the double d shaft or the A arms?? I was hoping to do the s10 clip with my sbc that already has the Speedway style ram horns on it.

  10. the-rodster
    Joined: Jul 2, 2003
    Posts: 6,960

    the-rodster
    Member

    If I recall correctly, they cleared, but pointed straight down at the crossmember.

    Rich

  11. gerry miller
    Joined: Feb 3, 2012
    Posts: 108

    gerry miller
    Member

    Thank You for posting this awesome build. Where did you get those clamps with the wingnuts. I have to get some? Looks Kick Ass!!!!!!!!!!!!

  12. the-rodster
    Joined: Jul 2, 2003
    Posts: 6,960

    the-rodster
    Member

    Harbor Freight has them cheap.

    Eastwood has them, not so cheap.

    They're called panel clamps.

    Rich

  13. glendale
    Joined: Mar 5, 2001
    Posts: 2,291

    glendale
    Member

    can you post that pic if you the manifold installed that might be the answer to my prayers.thanks man

  14. gerry miller
    Joined: Feb 3, 2012
    Posts: 108

    gerry miller
    Member

    Thanks for taking time to give the info on the clamps
    Gerry

  15. A guy on a homemade tools thread posted how he made a set, but Harbor Freight is probably faster and cheaper.

  16. Harrison
    Joined: Jan 25, 2002
    Posts: 7,133

    Harrison
    Member

    Skullet,

    'Bout time for an update on this one....

    Just sayin'

    JH

  17. the-rodster
    Joined: Jul 2, 2003
    Posts: 6,960

    the-rodster
    Member


    Just for you, Jim.


    I've been trying to tell myself that I wont' have to raise the driveshaft tunnel.

    But, after installing the driveshaft, and doing some measuring, I came to realize that half an inch of clearance, was just not enough.

  18. the-rodster
    Joined: Jul 2, 2003
    Posts: 6,960

    the-rodster
    Member

    It hurts my feelings to cut up nice floors......


    [​IMG]


    But it's gotta go....


    [​IMG]

  19. the-rodster
    Joined: Jul 2, 2003
    Posts: 6,960

    the-rodster
    Member

  20. the-rodster
    Joined: Jul 2, 2003
    Posts: 6,960

    the-rodster
    Member

    I started at the back, and started fabbing a new tunnel, and bump over the rear.

    [​IMG]

    [​IMG]

    [​IMG]

  21. the-rodster
    Joined: Jul 2, 2003
    Posts: 6,960

    the-rodster
    Member

    The crossmember under the seat also needed to be thinned out.

    [​IMG]

  22. the-rodster
    Joined: Jul 2, 2003
    Posts: 6,960

    the-rodster
    Member

  23. the-rodster
    Joined: Jul 2, 2003
    Posts: 6,960

    the-rodster
    Member

    The bottom of the rear seat needed some modifications to clear the new tunnel.

    [​IMG]

    Last edited: Mar 19, 2012
  24. daddio211
    Joined: Aug 26, 2008
    Posts: 6,012

    daddio211
    Member

    [​IMG]

    My wife sees an evil face in this picture.... With gills! LMAO

  25. the-rodster
    Joined: Jul 2, 2003
    Posts: 6,960

    the-rodster
    Member


    Tell her to put the bong down.

    Rich

  26. saratoga56
    Joined: Jul 24, 2008
    Posts: 67

    saratoga56
    Member
    from NY

    Best thread in a while.

  27. daddio211
    Joined: Aug 26, 2008
    Posts: 6,012

    daddio211
    Member

    Ha ha ha... :D

  28. Harrison
    Joined: Jan 25, 2002
    Posts: 7,133

    Harrison
    Member

    Looking good Rich!

    When is it going to be on the road?

    JH

  29. '54Caddy
    Joined: Sep 11, 2009
    Posts: 985

    '54Caddy
    Member

    Nice work Rich! looks factory.

    Josh

  30. the-rodster
    Joined: Jul 2, 2003
    Posts: 6,960

    the-rodster
    Member


    I thought that I could have it drivable by summer....

    I don't think that I'm gunna make it.

    Rich
