Hot Rods Valve seals or not?

Discussion in 'The Hokey Ass Message Board' started by Speedbump47, May 16, 2025.

  1. Speedbump47
    Joined: Dec 12, 2022
    Posts: 3

    Speedbump47

    1952 Chevrolet 235 with rebuilt tag on engine.
    Only the exhaust valves have seals. Shouldn't intake also have seals?
    Thanks in advance.

    Tow Truck Tom likes this.
  2. Tow Truck Tom
    Joined: Jul 3, 2018
    Posts: 3,250

    Tow Truck Tom
    Member
    from Clayton DE

    Any knowledge or history of engine?
    Are You sure they meant seals, not seats.
    Many jobs, for budget, just get exh. seats, 'cause intakes supposedly run cooler.:)

    Last edited: May 19, 2025
  3. Kevin Ardinger
    Joined: Aug 31, 2019
    Posts: 1,017

    Kevin Ardinger
    Member

    I would think all should have seals but if you were saving money on seals I would put them on the intakes as they are the ones that suck.

  4. earlymopar
    Joined: Feb 26, 2007
    Posts: 1,752

    earlymopar
    Member

    Seals or "seats"?

  5. Speedbump47
    Joined: Dec 12, 2022
    Posts: 3

    Speedbump47

    SEALS on exhaust only.

  6. Budget36
    Joined: Nov 29, 2014
    Posts: 15,062

    Budget36
    Member

    I’ve taken seals off intake and exhaust both. I’ve also seen intake only with seals. But have never come across exhaust only seals.
    I’ll look in my Motors manual later and see what it says for a ‘52 235.

    Edit: Motors says “remove locks, springs and seals…”

    this -to me- implies there should be seals on both intake and exhaust.

    Last edited: May 18, 2025
  7. Johnny Gee
    Joined: Dec 3, 2009
    Posts: 14,083

    Johnny Gee
    Member
    from Downey, Ca

    :p IMG_4107.jpeg IMG_4108.jpeg

    Tow Truck Tom and Beanscoot like this.
  8. jimmy six
    Joined: Mar 21, 2006
    Posts: 16,783

    jimmy six
    ALLIANCE MEMBER

    I’ve got the tool and put positive seals on every engine.. both intake and exhausts.

    Tow Truck Tom likes this.
  9. rockable
    Joined: Dec 21, 2009
    Posts: 4,961

    rockable
    ALLIANCE MEMBER

    Buick never put seals on exhaust valves on their Nailheads and the later V-8. There is no negative pressure, i.e. vacuum in and exhaust port, so it can't "suck" oil down the valve stem. There is heavy vacuum in the intake ports, however, especially at idle. With some valve guides materials, it is probably better to not have them on the exhaust but with todays silicon bronze, probably ok.

  10. THE FRENCHTOWN FLYER
    Joined: Jun 6, 2007
    Posts: 5,994

    THE FRENCHTOWN FLYER
    Member
    from FRENCHTOWN

    Just a little tangentially related fun fact:

    I once ran a series of dyno tests on a SBF - running with valve stem seals, and then removing all the valve stem seals and repeating the test.
    The oil consumption went from 2500 mi/qt to 400 mi/qt.

    Algoma56 likes this.
  11. Rickybop
    Joined: May 23, 2008
    Posts: 10,531

    Rickybop
    Member

    I would venture a guess that whoever rebuilt the heads intended to put the seals on the intake valves only.
    But, oops...

    rockable and Budget36 like this.
